Hydroblasting Robot HighMate V Serie
Jun 23,2025
HighMate V40 is improved on the basis of HighMate V30. It is more advanced, not only showed by its 20% higher efficiency, but also because of the autonomous navigation system which enables an unmanned operation. On the other hand, the upgraded modular design and less consumables make it easier for maintenance as well.
HighMate V45 uses the basis of V40, with operational improvement and an optional hinge system for greater reach. The hinge system allows the robot to have a much better curvature adaptability, which can cover a minimum radius of 4 meters.
HighMate V40 Ultra is the latest hydroblasting robot developed by RobotPlusPlus. Featuring the innovative four-wheel flexbile magnetic platform design, the robot offers strong curvature adaptability, excellent obstacle crossing performance, stable attachment ability, advanced intelligence and wide range of applications. It is capable of covering over 98% of the ship hull surface preparation. Furthermore, it can be connected to a recovery pump to achieve highly efficient waste recovery, making it an all-around robotic solution.
HighMate V40E Pro is specially designed for cleaning the narrow area of the working surface, especially large flat surface area and bottom cleaning. Compared to V40E, V40E Pro has a wider cleaning dome, allowing the robot to increase its efficiency without influencing its curvature adaptability at the same time. The smaller platform allows in to go across the space between dock blocks easily, which a high cleaning efficiency up to 60 m²/hour.
HighMate Ex V10 is equipped with explosion-proof components to fit the need in oil and gas industry. Ex V10 rating is EX 11B T4 level of explosion proof grade, able to operate near active tanks using enclosed electrical drive.
Product Features
1. Smart Operation: The robot can be controlled by an operator on the ground using a remote control. It has three modes of operation: manual, semi-auto or cruise mode, and automatic mode. With a high level of automation, it significantly reduces the need for manual labor, greatly decreasing work intensity.
2. Efficient Surface Preparation: Utilizing ultra-high-pressure water jet technology, the robot can effectively remove rust and old paint from the surfaces of large structures, such as ship hulls. Its efficiency is several times that of manual job, greatly enhancing the operation.
3. Eco-Friendly Design: The wastewater containing paint and rust debris generated during the operation process can be recovered and treated using a vacuum recovery system, minimizing environmental pollution.
4. Magnetic Technology: The robot uses permanent magnetic adhesion technology, providing excellent wall-adhering capabilities, enabling it to work steadily on vertical and overhead surfaces.
5. Two-wheel Driving System: The robot employs a two-wheel drive system with differential steering, offering strong load capacity and climbing ability. It moves quickly and responds flexibly.
6. Safety Design: During operation, the robot is equipped with two or more fall arrestors, ensuring there is no risk of falling from heights.
7. Multi-functional: In addition to surface preparation for ships, this robot can also be used on steel surfaces of storage tanks, spherical tanks, bridges, and other structures where magnetic attraction is applicable.
Technical Parameter
| HighMate V40 Specifications | |||
| Efficiency | 35-55 m2/h | Dimension | 810*1154*552 mm |
| Weight | 91 kg | Cleaning Width | 300 mm |
| Pressure | 3000 bar | Protection Level | IP65 |
| FlowRate | 18-52 L/min | Minimum Curvature | 8 m |
| HighMate V45 Specifications | |||
| Efficiency | 45-65 m2/h | Dimension | 825*1200*525 mm |
| Weight | 97 kg | Cleaning Width | 310 mm |
| Pressure | 3000 bar | Protection Level | IP65 |
| FlowRate | 18-52 L/min | Minimum Curvature | 4 m |
| HighMate V40 Specifications | ||||
| Dimension (L×W×H) | 1105×575×526 mm/1181×517×477 mm | |||
| Weight | 86/89 kg | Power | 1.2 kW/1.5 kW | |
| Cleaning Width | 310/400 mm | Power Supply | 220VAC,48V DC | |
| Production Rate | 40-60 m²/h (WJ2.0/WJ2.5) (Efficiency varies with parameters such as operators 'proficiency, coating type,and water pressure) | |||
| Remote Control Range | 80 m | Working Temperature | 0-55℃ | |
| Protection Grade | IP 68 | No.of Nozzles | 16/20 | |
| Max Flow Rate | 52 L/min | Max Pressure | 3000 bar | |
| HighMate V40E Specifications | ||||
| Dimension (L×W×H) | 1105×575×526 mm/1181×517×477 mm | |||
| Weight | 86/89 kg | Power | 1.2 kW/1.5 kW | |
| Cleaning Width | 310/400 mm | Power Supply | 220VAC,48V DC | |
| Production Rate | 40-60 m²/h (WJ2.0/WJ2.5) (Efficiency varies with parameters such as operators 'proficiency, coating type,and water pressure) | |||
| Remote Control Range | 80 m | Working Temperature | 0-55℃ | |
| Protection Grade | IP 68 | No.of Nozzles | 16/20 | |
| Max Flow Rate | 52 L/min | Max Pressure | 3000 bar | |
| HighMate Ex V10 Specifications | |||
| Efficiency | 35-55 m2/h | Dimension | 740*1018*510 mm |
| Weight | 100 kg | Cleaning Width | 300 mm |
| Pressure | 3000 bar | Protection Level | IP65 |
| FlowRate | 30-45 L/min | Minimum Load | 100 kg |
