Swing Arm Multi Purpose Robot HighMate A Serie


Swing Arm Robot HighMate A10/20 Serie is an open blasting (hydro/abrasive/dry-ice/wet) and cleaning robot. From a practical application perspective, the Swing arm multi-function robot excels in areas such as steel structure sandblasting, ship maintenance and rust removal, oil tank cleaning, bridge corrosion protection, and the handling of large industrial components.

Category:

Products

Keywords:

Swing Arm Multi Purpose Robot HighMate A series

RobotPlusPlus

BeeBot Series Product

Hydroblasting

HighMate

shipyard robot

marine robot

Swing arm multi-function robot company

Product Details

Swing Arm Robot HighMate A10/20 series is a compact open blasting (hydro/abrasive/dry-ice/wet) and cleaning robot. The modular design allows one man to replace the open cleaning module with a vacuum dome module on a V40/V45 in 20 minutes. The swing speed and span can be adjusted. Two versions are available for high and low curvature.



Product Features


1. Modular Design: Easier maintenance and servicing.
2. Intelligent Control System: Highly integrated with one-click lane change and positioning navigation.
3. Multiple Unit Compatibility: Compatible with various tools and fixtures, capable of equipping high-pressure water nozzles, sandblasting guns, paint spray guns, etc., to meet different requirements.
4. Wide Range of Applications: Strong adaptability to curved surfaces, capable of operating on vertical surfaces, flat surfaces, and curved surfaces.



Technical Parameter


Description
Swing Arm Robot HighMate A10 series is a compact open blasting (hydro/abrasive/dry-ice/wet)and cleaning robot. The modular design allows one man
to replace the open cleaning module with a vacuum dome module on a V40/V45 in 20 minutes. The swing speed and span can be adjusted. Two versions are available for high and low curvature.
Specifications
Size 1127×915×587 mm
Weight 85 kg Power 1.2 Kw
AC220V/50Hz
Cleaning width 1400 mm Obstacle crossing ≤18 mm
Min curvature radius 3m (hinge joint
version)
Max speed 10 m/min
Production Rate 30-150  m²/h
(Efficiency varies with parameters such as operators 'proficiency,
coating type,and water pressure)
Control mode Remote control-Manual/Semi-autonomous /Autonomous
Surface quality WJ1 to 4 or
less
Maximal load capacity 150 kg
Pump requirement Pressure 300-2,800 Bars Flow 18-150 I/min

In the fields of industrial manufacturing and heavy structure maintenance, efficiency, safety, and stability are always core concerns for enterprises. The Swing arm multi-function robot was developed to meet these needs, specifically designed for high-intensity surface treatment and industrial cleaning scenarios. This equipment employs an innovative swing-arm structure, achieving wide-area coverage in limited spaces, reducing equipment movement frequency, and significantly improving work efficiency. Compared to traditional manual sandblasting or cleaning methods, it not only reduces labor intensity but also effectively avoids safety hazards from dangerous environments such as high altitudes and confined spaces, making it an important piece of equipment for industrial automation upgrades. For shipyards, steel structure manufacturers, bridge maintenance units, and the energy industry, this is an intelligent solution that balances performance and economy.

Its structural design and control system demonstrate a high degree of specialization. Modular functional interfaces support multiple operation methods such as sandblasting, rust removal, high-pressure water jet cleaning, and spraying, allowing a single machine to adapt to different process requirements and reduce repetitive investment costs. The equipment is equipped with an intelligent control system that supports remote control, semi-automatic, and automatic operation modes. The user interface is intuitive and easy to understand, allowing even novice personnel to quickly learn how to use it, significantly reducing training and manpower investment. A stable power system and precise swing control ensure a uniform spray trajectory, guaranteeing standardized and repeatable treatment results. Meanwhile, the robust and durable chassis adapts to complex industrial environments, enabling continuous operation under high humidity, high dust, or high-pressure conditions, meeting the demands of continuous work.

From a practical application perspective, the Swing arm multi-function robot excels in areas such as steel structure sandblasting, ship maintenance and rust removal, oil tank cleaning, bridge corrosion protection, and the handling of large industrial components. Its flexible swing-arm movement can conform to curved and vertical surfaces, achieving high coverage and efficiency. Through intelligent control and automated execution, companies can not only improve production speed but also significantly reduce labor costs and operational risks, further enhancing their market competitiveness.
